Raymarine E-Series Installation Manual

12 E-Series Installation Manual
Single display system
This simple system incorporates a single E-Series display with a DSM 300 and radar.
Power Cables
Red 12V or 24V DC
Black 0V
Ground/Earth RF Ground
Third party equipment
NMEA multiplexer
Fast heading sensor
RS232 interface
Autopilot
To:
Video player
Onboard camera
DVD player
To:
SeaTalk system
Remote audible alarm
RF ground/earth
PC via interface box
SeaTalk high speed
Radar
Key
Power
Supplied
Not supplied/
accessory
Crossover
coupler
D7204-1
Transducer
Power NMEA
Video IN
SeaTalk/Alarm out
Open array scanner
Radome scanner
E-series display
DSM 300
or
