Raymarine E-Series Installation Manual

14 E-Series Installation Manual
A typical two node system incorporating two displays
Power Cables
Red 12V or 24V DC
Black 0V
Ground/Earth RF Ground
To:
Video player
Onboard camera
DVD player
To:
SeaTalk system
Remote audible alarm
RF ground/earth
PC via interface box
Third party equipment
NMEA multiplexer
Fast heading sensor
RS232 interface
Autopilot
Key
Not supplied/
accessory
Supplied
Open array scanner
Radome scanner
or
To:
Video player
Onboard camera
DVD player
SeaTalk high speed
Power Power
SeaTalk2/NMEA
Video In
SeaTalk/Alarm out
E-series display
D7346-1
Video In
E-series display
Crossover
coupler
SeaTalk high speed
