22 E-Series Installation Manual
3.2 Cables
This section details how to instal and connect all the relevant cables to your E-Series
Display.
Siting and securing cables
When installing system cables, please note the following:
• All cables should be adequately secured, protected from physical damage and
exposure to heat. Avoid running cables through bilges or doorways, or close to
moving or hot objects.
• Acute bends must be avoided.
• Where a cable passes through an exposed bulkhead or deckhead, a watertight
feed-through should be used.
• Secure cables in place using tie-wraps or lacing twine. Coil any extra cable and tie
it out of the way.
• Do not pull cables through a bulkhead or deckhead using a cord
attached to the connector as this could damage the connections.
• Do not remove the SeaTalk High Speed blanking plug from the rear of the
display until such time as you are ready to connect the cable. Failure to adhere to
this, may result in the ingress of water and permanent damage to the display.
What cables do I need to connect?
To ensure that your E-Series Display functions correctly, you will need to connect the
following cables:
•Power cable.
• SeaTalk/Alarm Out cable (if SeaTalk system connected).
• NMEA cable (if third party equipment, NMEA multiplexer, fast heading sensor,
RS232 interface or course computer fitted).
•SeaTalk
2
cable (if Sea Talk
2
system connected).
• SeaTalk High Speed cable (if a DSM or second display is fitted).
• Video In cable (if a video player, on-board camera or DVD player fitted).
• Radar cable (not supplied).
• VGA Out cable (if an M1500 monitor or additional screen is fitted).
