Raymarine E-Series Installation Manual

Chapter 2: System Integration 15
An example of a three (or more) node system
To: Fast heading sensor NMEA GPS DSC radio
To: SeaTalk system Remote alarm RF ground/earth PC via interface box Additional E-Series displays
To: SeaTalk
2
system
Additional E-Series displays
To: NMEA multiplexer
To: 3rd party equipment
Raymarine equipment
To: Video player Onboard camera DVD player
To: Video player Onboard camera DVD player
To: VGA/SVGA monitor Plasma screen M1500 monitor
Power Cables Red 12V or 24V DC Black 0V Ground/Earch RF Ground
Key
Not supplied/ accessory Supplied
D7205-1
Additional NMEA connections
Radar
Open array scanner
SeaTalk high speed
SeaTalk high speed
Radome scanner
or
Power
Video in
SeaTalk
2
Video in
VGA out
SeaTalk high speed
Power
NMEA 0183
SeaTalk/alarm out
Power
DSM 300
Additional
displays
E-series display (master display)
Additional E-series display
SeaTalk
HS
switch
Power
