30 E-Series Installation Manual
Pedestal adaptor cable
(2.5 metres)
PAGE
ACTIVE
WPTS
MOB
MENU
DATA
CANCELOK
RANGE
IN
OUT
D7328-1
Open Array
Boats DC
Power Supply
E-Series Display
Power to display
Power to open array
Note: The power supply for both the display
and the open array must be of the same
voltage (using a convertor if necessary) and
from a common supply source e.g. the same
battery or power breaker.
