4.4.7 RAH Module 10: Test with the RAH ‘Green Card’ Page 45
4.4.7 RAH Module 10: Test with the RAH ‘Green Card’
In the module 10 of the Rayocomp PS 10 it is not only possible to harmonise
the RAH-programmes stored on a RAH ‘Green Card’, but also to test them. As
an example, the RAH-programmes, that were selected in the last testing and
stored on the RAH ‘Green Card’, could now be checked again. It is also
possible to compile your own RAH-programmes, to store them on the RAH
‘Green Card’ and then to test them.
Please insert a programmed RAH ‘Green Card’ into the Rayocomp PS 10 and
press the following key:
The RAH-programmes stored on the card will now be read into the Rayocomp
PS 10 and are then available for testing. The display shows then for example:
Currently, the RAH-programme 04.22
is selected. It is the first (fig. 2) of 10
RAH-programmes to be tested (fig. 3).
The note: Card (fig. 1) appears on the
display, to show the user immediately,
that currently, the values of a RAH
‘Green Card’ are tested.
32 1
As already described in chapter 4.4.5, all respective RAH-programmes can
now be tested and stored.
Please also read the chapter :
4.4.8 Important tips and tricks for testing with the RAH-Module 10
