PELLET STOVES Chapter 3
red
INSTALLATION AND USE MANUAL
page 21
Installation and assembly Technical service - Rights reserved - Reproduction prohibited
Technical characteristics MARGHERITA-GARDENIA Mod. HYDRO
Overall thermal power Max.
11,6 kw (9976 kcal) / 10,0 kw (8600 kcal)
Overall thermal power Min.
3,6 kw (3096 kcal) / 2,5 Kw (2150 kcal)
Yield at maximum
91,5%
Yield at minimum
96,0%
Temperature of exhaust smoke at maximum
140°C
Temperature of exhaust smoke at minimum
70°C
Dust
11 mg/Nm3 (13% O2)
7 mg/MJ
CO at 13%O
²
at minimum and maximum
0.034 — 0.011%
CO
2
at minimum and maximum
6,7% – 8,7%
Mass of smoke at minimum and maximum
3,6 – 11,0 g/sec
Suggested draught at max power
0,10 mbar – 10 Pa
Suggested draught at min power
0,05 mbar – 5 Pa
Hopper capacity
37 litres
Fuel pellet type
Pellet diameter 6-8 mm. Length range 5/30 mm
Pellet consumption per hour
Min ~ 0,8 kg/h * Max. ~ 2,5 kg/h *
Operating time between re-fuelling
Al min ~ 36 h * Al max. ~ 10 h *
Heatable volume m
3
249/40 – 285/35 – 333/30 **
Combustion air inlet
External diameter 50 mm.
Smoke outlet
External diameter 80 mm.
Maximum absorbed electrical power
Max. 420 W – Med. 120 W
Power supply frequency and voltage
230 Volt / 50 Hz
Net weight
175 Kg.
Weight with packaging
185 Kg.
* Data that may vary depending on the type of pellets used.
**Heatable volume based on demand of cal/m
3
40-35-30 (respectively 40-35-30 Kcal/h for m
3
)
Appliance suitable for installation in a shared flue.
