3.1.4. Technical characteristics
Technical characteristics PRIMULA - ORCHIDEA Mod. HYDRO
Overall thermal power Max.
21 kw (18056 kcal) / 17,0 kw (14617 kcal)
Overall thermal power Min.
4,4 kw (3784 kcal) / 3,0 Kw (2580 kcal)
Yield at maximum
92,5%
Yield at minimum
95,0%
Temperature of exhaust smoke at maximum
150°C
Temperature of exhaust smoke at minimum
71°C
Dust
1,7 mg/Nm3 (13% O2)
1,2 mg/MJ
CO at 13%O
²
at minimum and maximum
0.040 — 0.012%
CO
2
at minimum and maximum
7,03% – 12,49%
Mass of smoke at minimum and maximum
4,5 – 12,6 g/sec
Suggested draught at max power
0,10 mbar – 10 Pa
Suggested draught at min power
0,05 mbar – 5 Pa
Hopper capacity
44 litres
Fuel pellet type
Pellet diameter 6-8 mm. Length range 5/30 mm
Pellet consumption per hour
Min ~ 0,9 kg/h * Max. ~ 4 kg/h *
Operating time between re-fuelling
Al min ~ 28 h * Al max. ~ 7 h *
Heatable volume m
3
366/40 – 418/35 – 487/30 **
Combustion air inlet
External diameter 50 mm.
Smoke outlet
External diameter 80 mm.
Maximum absorbed electrical power
Max. 420 W – Med. 120 W
Power supply frequency and voltage
230 Volt / 50 Hz
Net weight
190 Kg.
Weight with packaging
200 Kg.
* Data that may vary depending on the type of pellets used.
**Heatable volume based on demand of cal/m
3
40-35-30 (respectively 40-35-30 Kcal/h for m
3
)
Appliance suitable for installation in a shared flue.
