Reftek 130-MC User Manual

Rev G REF TEK 130 Multi-Channel Users Guide 5/14/2021
96223-00-UG
54 Reftek Systems Inc.
Channels 13-18 connector
The channel 13-18 connector on the 130-03 provides inputs for an external sensor. The internal
A/D card must be configured in order to work with an external sensor.
Recorder
Connector
130
Pin
Name
Direction
Electrical Desc
Voltage Range
Note
A
CH13+
In
Channel 13 input +
±10 Volts
B
CH13-
In
Channel 13 input -
±10 Volts
C
CH14+
In
Channel 14 input +
±10 Volts
D
CH14-
In
Channel 14 input -
±10 Volts
E
CH15+
In
Channel 15 input +
±10 Volts
F
CH15-
In
Channel 15 input -
±10 Volts
G
AGND
In
Analog ground
H
PWR
Out
Sensor power
10-15 Volts
1, 2, 3
J
PGND
-
Power ground
K
CH16+
In
Channel 16 input +
±10 Volts
L
CH16-
In
Channel 16 input -
±10 Volts
M
CH17+
In
Channel 17 input +
±10 Volts
N
CH17-
In
Channel 17 input -
±10 Volts
P
Ch18+
In
Channel 18 input +
±10 Volts
R
CH18-
In
Channel 18 input -
±10 Volts
S
CALEN+
Out
Test Enable
0-5 Volts
4
T
No connect
U
No connect
V
No connect
Note: 1 = Tracks main input voltage
Note: 2 = Protected by self-resetting fuse
Note: 3 = Output on/off controlled by software
Note: 4 = provided by RT580 board
