Sample 130-03 LCD displays
LCD
Display
Initial power up LCD
RAM Used out of Total
Disk (Used out of Total)
Date, Time and Temperature
GPS status
Position
Power status of power to the 130 and battery backup power:
Acceptable Range: 10-15Volts
Backup Range: 2.2-3.6 Volts
Battery Charger voltage
Modem Status:
Init = Initializing the modem
Idle = Waiting
Dialing = Dialing out
Connected
Acquisition Status:
Stream Indicator:
C = Continuous
V = Vote
X = External
Firmware
Version
Date
Firmware
Unit ID
Used Kb
Total Available RAM
Used MB Total Available MbDisk #
Date Time
Internal temperature
GPS StatusMinutes since last lock
GPS Position
Main powerBattery backup power
MODEM: Idle
Requested State Actual State
Event Count StreamIndicator
---- Inactive
else trigger type
