Rev G REF TEK 130 Multi-Channel Users Guide 5/14/2021

96223-00-UG

56 Reftek Systems Inc.

130-03 Boards

RT580 Lid Board

RT526 Flash Board

RT608-B06 A/D (1-6)

RT608-B07 A/D (7-12)

RT608-B08 A/D (13-18)

RT506 CPU Board

130-8263 Base

130-9279 Gasket
