Rev G REF TEK 130 Multi-Channel Users Guide 5/14/2021
96223-00-UG
Reftek Systems Inc. 61
4. Handle the drive by grasping the sides of the drive with the other hand.
5. Install a newly formatted drive in either slot by holding (ONLY) onto the sides of the Compact Flash
and inserting into the well or reader (as shown in Figure 4.3).
6. The LED, for the well slot, should turn “Green”.
When using the Compact Flash™ with a Compact Flash™ Reader:
1. Grasp only the edges while inserting the drive into the Compact Flash Reader.
2. Grasp only by edges or tab to install or remove the drive.
