5.2 Overview table of the parts of the device
Element
Description
Function
A
Cover
Closes the grinding chamber
B
Warning sign
Warning clamp grinding jar
C
Clamping unit for grinding jar
Clamps grinding jar on the support
CA
Locking sleeve
Prevents the twist grip from being turned accidentally
CG
Handle for clamping unit (lead frame)
Handle to clamp the grinding jars
CS
Base of clamping unit
Secures the clamping unit in the latching brackets
CW
Thread of clamping unit
Thread of clamping unit
DB
Grinding jar vessel
Sample vessel
DD
Grinding jar lid
Closes the sample vessel
E
Counterbalance weight
Counterbalance for the grinding jar
F
Rotary knob
Positions the counterbalance
FS
Weight scale
Adjusts the grinding jar weight
G
Sign with instruction to read the
operating manual
Sign pointing out the need to read the operating
manual
H
Pin closing mechanism
Safety lock for the cover
I
Damper for cover
Secures the cover when it is open
J
Closing mechanism for the opening
Support for pin closing mechanism
K
Control panel
Device controller
MT
Grinding jar plate
Support for the grinding jar
NR
Emergency release
Opening for the emergency release key
O
Turntable
Support for the grinding jar plate
P
Latching bracket
Supports the clamping unit
Q
Safety Slider
Safety component – checking whether the clamping
unit is inserted and clamped
R
Display window
Displays the safety function
S
Serial interface
Interface for communication with the device
T
Support for safety fuse
Access to the device fuse
U
Main switch
Disconnects the device from the mains
V
Air opening
Air suction
W
IEC socket
Power supply for the power cable
X
Housing fan
Exhaust opening
Y
Type plate
Description of device parameters
Z
Warning sign to pull out the plug
Warning of electric shock
