Operating the Device
35
NOTICE
The additional weight (EZ) must be removed again when using light (small) grinding jars!
5.11 Releasing the grinding jar clamping mechanism
Fig. 20: Releasing the grinding jar clamping mechanism
• Pull the red sleeve (CA) upwards.
• Turn the three-star grip to the left to release the grinding jar.
• Keep turning the three-star grip to the left until the grinding jar clamping
mechanism can be removed.
5.12 Opening the Clamping Mechanism with the Opening Aid for the Clamping Unit
• The opening aid for the clamping unit (KS) [accessory] can be used to loosen or tighten the
clamping unit (C).
Fig. 21: Inserting the opening aid for the clamping unit on the PM 100 and PM 100 CM
CA
C
KS
CA
