Operating the Device
37
5.13 Power failure during grinding
If the power fails during grinding, grinding will be interrupted. All parameters are retained, and
the remaining grinding time is saved. When the device is switched on again, a corresponding
message appears in the display.
You can continue the process by pressing the START button. The automatic saving of the
remaining grinding time means the grinding then continues until the end of the originally set
grinding time.
For safety reasons the device must be opened and the grinding chamber inspected. Grinding
then continues automatically when the lid is closed.
The process is aborted by pressing the STOP button. .
5.14 Grinding Jar Selection for Different Sample Materials
This device is only suitable for use with grinding jars from Retsch GmbH with a nominal volume
of 12 ml - 500 ml.
They are available in the following materials:
• Agate
• Sintered corundum
• Zirconium oxide
• Stainless steel
• Special steel
• Tungsten carbide
5.15 Sample quantity
NOTICE
If the fill level in the grinding jar is too high or too low, this will impair the milling result and may
cause damage (increased abrasion) to the grinding set.
5.15.1 Guides for material quantity and balls for PM100 and PM100CM
The PM100 and PM100CM are only suitable for grinding jars with a nominal volume of 12-500
ml.
The PM200 is only suitable for grinding jars with a nominal volume of 12-125 ml.
Grinding jar
volume
Sample
volume
Max. feed
size
Ball filling (unit)

5 mm

7 mm

10 mm

15 mm

20 mm

30 mm

40 mm
12 ml
≤ 5 ml
< 1 mm
50
15
5
-
-
-
-
25 ml
≤ 10 ml
< 1 mm
100
25
8
-
-
-
-
50 ml
5 – 20 ml
< 3 mm
200
45
10
7
3
-
-
80 ml
10 – 35 ml
< 4 mm
250
70
25
10
5
-
-
125 ml
15 – 50 ml
< 4 mm
500
110
30
18
7
-
-
250 ml
25 – 120 ml
< 6 mm
1200
220
50
45
15
6
-
500 ml
75 – 220 ml
< 10 mm
2000
440
100
70
25
8
4
