Retsch PM100 - Inserting the Grinding Jar

Operating the Device
31
NOTE
Wear or damage of the device
Operation without grinding set
− During operation of the device without grinding set, excessive wear or
damage to the device may occur.
• Operate the device only with a grinding set mounted.
NOTICE
H0011
Wear or damage to the grinding set
Different materials
– During the operation of the grinding set consisting of different materials,
increased wear or damage to the grinding set is possible.
• Only use grinding sets, where all parts are made of the same
material.
5.8.1 Inserting the grinding jar
Fig.
1
5: Clamping the grinding jar
• If necessary clean the grinding jar plate (MT) and the anti-rotation pin (VS).
• Turn the grinding jar label (DE) to the same side as the anti-rotation pin.
• Place the grinding jar in the grinding jar support.
MT
VS
DE
