Frame
Model
①
Dimensions [mm]
Screw
size
②
Net
weight
[kg]
W H D w h d Ø
J
③
75K0 325 760 342 200 727 334 11.0 M10 54.0
J
③
90K0 325 760 342 200 727 334 11.0 M10 61.0
K
③
110K 385 923 350 250 893 342 11
M8 /
M10
④
71.7
K
③
132K 385 923 350 250 893 342 11
M8 /
M10
④
76.6
Tab. 1-4: EFC x610 3P 400 VAC dimensions
Frame
Model
①
Dimensions [mm]
Screw
size
②
Net
weight
[kg]
W H D w1 w2 h d Ø
B 0K40 95 166 124 60 66 156 116 4.5 M4 1.1
B 0K75 95 166 124 60 66 156 116 4.5 M4 1.1
C 1K50 95 206 124 60 66 196 116 4.5 M4 1.4
C 2K20 95 206 124 60 66 196 116 4.5 M4 1.4
D 3K00 120 231 124 60 66 221 116 4.5 M4 1.8
D 4K00 120 231 124 60 66 221 116 4.5 M4 1.8
Tab. 1-5: EFC 5610 3P 400 VAC dimensions (cold plate models)
●
①
: The complete type code for frequency converter is:
EFCX610-xKxx-xPx-MDA-xx-NNNNN-xxNN, see "Appendix: Type
Coding" in the Operating Instructions.
E.g., type code for EFC 5610 5K50 (3P 400 VAC model) is:
EFC5610-5K50-3P4-MDA-7P-NNNNN-NNNN.
●
②
: 4 screws are needed for mounting of EFC x610.
●
③
: ONLY available with EFC 5610.
●
④
: see chapter 2.2 "Cable Specifications" on page 13 for de-
tails.
Bosch Rexroth AG
Mechanical Installation
EFC 3610 / EFC 5610
8/87
DOK-RCON03-EFC-X610***-QU11-EN-P
