● Information on cable size, fuse, screw torque, see chapter 2.2.
● Information on terminals, see chapter 2.3.
● ①: NPN modes, see chapter 2.3.2.
● ②: STO (Safe Torque Off) function only applies to models of EFC
5610. See Operating Instructions for details.
● *: Can be disconnected by disassembly of a screw. See Operating
Instructions for details.
● Pulse input can ONLY be set via 'Multi-function digital input X5'.
● When analog current input function is applied, the supply voltage
of analog input terminal can not exceed +5 V.
Bosch Rexroth AG
Electric Installation
EFC 3610 / EFC 5610
12/87
DOK-RCON03-EFC-X610***-QU11-EN-P
