C1: Motor and system parameters
Code Name Setting range Default Min. Attri.
C1.01 Motor parameter tuning
0: Inactive
1: Static auto-tuning
2: Rotational auto-tuning
①
0 – Stop
C1.02 Expert mode
0: Standard mode
1: Expert mode
0 – Stop
C1.05 Motor rated power 0.1...1,000.0 kW DOM 0.1 Stop
C1.06 Motor rated voltage 0...480 V DOM 1 Stop
C1.07 Motor rated current 0.01...655.00 A DOM 0.01 Stop
C1.08 Motor rated frequency 5.00...400.00 Hz 50.00 0.01 Stop
C1.09 Motor rated speed 1...60,000 rpm DOM 1 Stop
C1.10 Motor rated power factor
0.00: Automatically identi-
fied
0.01...0.99: Power factor
setting
0.00 0.01 Stop
C1.11
Motor poles
①
2...256 4 1 Stop
C1.12 Motor rated slip frequency 0.00...60.00 Hz DOM 0.01 Stop
C1.15 Torque constant 0.01…200 DOM 0.01 Stop
C1.16 Back emf voltage constant
0.0...6550.0 V/1000 min
-1
0.0 0.1 Read
C1.17 Motor rated torque 0.0…6553.5 N.m DOM 0.1 Read
C1.20 Motor no-load current 0.00...[C1.07] A DOM 0.01 Stop
C1.21 Stator resistance 0.00...200.00 Ω DOM 0.01 Stop
C1.22 Rotor resistance 0.00...200.00 Ω DOM 0.01 Stop
C1.23 Leakage inductance 0.00...600.00 mH DOM 0.01 Stop
C1.24 Mutual inductance 0.0...6,000.0 mH DOM 0.1 Stop
C1.25 Rotor leakage inductance 0.00...600.00 mH DOM 0.01 Stop
C1.69
Motor thermal model protection
setting
0: Inactive
1: Thermal model active
2: Current monitoring ac-
tive
0 – Stop
C1.70 Motor overload pre-warning level 100.0...250.0 % 100.0 0.1 Run
C1.71 Motor overload pre-warning delay 0.0...20.0 s 2.0 0.1 Run
