E9: Protection and error parameters
Code Name Setting range Default Min. Attri.
E9.00 Automatic error reset attempts 0...3 (0: Inactive) 0 – Stop
E9.01 Automatic error reset interval 0.1...60.0 s 10.0 0.1 Stop
E9.02
Automatic error reset attempts re-
start time
0…65,535 0 1 Stop
E9.05 Last error type – – – Read
E9.06 Second last error type – – – Read
E9.07 Third last error type – – – Read
E9.10 Output frequency at last error – – 0.01 Read
E9.11 Setting frequency at last error – – 0.01 Read
E9.12 Output current at last error – – 0.1 Read
E9.13 Output voltage at last error – – 1 Read
E9.14 DC-bus voltage at last error – – 1 Read
E9.15
Power module temperature at last
error
– – 1 Read
E9.50 Last warning type – 0 – Read
E9.51 Second last warning type – 0 – Read
E9.52 Third last warning type – 0 – Read
E9.97 Last error detail 00000...FFFFF 0 – Read
E9.98 Second last error detail 00000...FFFFF 0 – Read
E9.99 Third last error detail 00000...FFFFF 0 – Read
Value range of E9.05...E9.07:
0: No error
1: OC-1, overcurrent at constant speed
2: OC-2, overcurrent during acceleration
3: OC-3, overcurrent during deceleration
4: OE-1, overvoltage at constant speed
5: OE-2, overvoltage during acceleration
6: OE-3, overvoltage during deceleration
8: UE-1, undervoltage during run
9: SC, surge current or short circuit
10: IPH.L, input phase loss
11: OPH.L, output phase loss
12: ESS-, soft start error
20: OL-1, converter overload
