REXROTH VFC 3610 - LED Indicator

3.1.3 LED Indicator
Mode Run FWD REV
Power
①
Power off Off Off Off Off
Ready Off Green / Off Off / Green Red
Run (FWD) Green Green Off Red
Run (REV) Green Off Green Red
Run pending Blinks in green
(Short green
long dark)
Green / Off Off / Green Red
DC-braking at start
Direction change dead time
Deceleration stop phase Blinks in green
(Short dark
long green)
Green / Off Off / Green Red
DC-braking at stop
Warning with FWD Green Green Off
Blinks in red
(Short dark
long red)
Warning with REV Green Off Green
Blinks in red
(Short dark
long red)
Warning at stop Off Green / Off Off / Green
Blinks in red
(Short dark
long red)
Error Off Green / Off Off / Green
Blinks in red
(Short red
long dark)
Tab. 3-1: LED indicator status
●
①
: Available on dust cover or when neither the LED panel nor the
dust cover is installed.
● The frequency converter stops if FWD and REV commands are ac-
tive at the same time.
