2.3.2 Control Terminals
Control terminals figure
Fig. 2-5: Control circuit terminals
The frequency converter might be damaged!
Please make sure that the power supply of the frequency converter has been
switched off before plugging or unplugging the connector.
The terminal block is ONLY for wiring convenience, which CANNOT
be used for fixing the cables. Additional measures need to be taken
by users for cable fixing purpose.
22/91
Electric Installation
Rexroth Frequency Converter VFC
3610 / VFC 5610
Bosch Rexroth AG R912005518_Edition 16
