E5: Extended function parameters
Code Name Setting range Default Min. Attri.
E5.01
High resolution output current
filter time
5...500 ms 40 1 Run
E5.02 User-defined speed scaling factor 0.01...100.00 1.00 0.01 Run
E5.05 Pump dry protection threshold 0.0 %…[E5.08] 30.0 0.1 Run
E5.06 Pump dry protection delay
0.0…300.0 s
(0.0: Inactive)
0.0 0.1 Run
E5.07 Pump dry protection delay at start-up 0.0…300.0 s 30.0 0.1 Run
E5.08 Pump leakage protection threshold 0.0…100.0 % 50.0 0.1 Run
E5.09 Pump leakage protection delay
0.0…600.0 s
(0.0: Inactive)
0.0 0.1 Run
E5.10 Pump leakage protection delay at start-up 0.0…600.0 s 60.0 0.1 Run
E5.15 Sleep level 0.00...[E0.09] Hz 0.00 0.01 Run
E5.16 Sleep delay 0.0...3,600.0 s 60.0 0.1 Run
E5.17 Sleep boost time 0.0...3,600.0 s 0.0 0.1 Run
E5.18 Sleep boost amplitude 0.0...100.0 % 0.0 0.1 Run
E5.19 Wake up level 0.0...100.0 % 0.0 0.1 Run
E5.20 Wake up delay 0.2...60.0 s 0.5 0.1 Run
64/91
Start-up
Rexroth Frequency Converter VFC
3610 / VFC 5610
Bosch Rexroth AG R912005518_Edition 16
