2.2 Cable Specifications
2.2.1 Power Connection
Cable specification for international without USA / Canada
● Use copper wires specified for 90 ℃ or above.
● Insulation based on IEC60364-5-52.
● Cable with concentric shielding must be used.
● According to IEC61800-5-1, PE cable must be at least 10 mm
2
or a
double PE cable must be used.
● *: If additional labels available with the terminals of 0K40...7K50,
please refer to the torque data on labels.
VFC x610
Model
Fuse (gG)
Power cables installation mode
PE Cable Torque / Screw
B1 B2 E
[A]
[mm
2
] [mm
2
]
[N·m / lbf·in] (Mx)
0K40 10.0 2.5 2.5 2.5
10.0
0.8* / 7.0 (M3)
2.5*2
0K75 16.0 2.5 2.5 2.5
10.0
0.8* / 7.0 (M3)
2.5*2
1K50 25.0 4.0 4.0 2.5
10.0
0.8* / 7.0 (M3)
4.0*2
2K20 32.0
6.0
①
6.0
①
4.0
10.0
0.8* / 7.0 (M3)
6.0*2
Tab. 2-1: 1P 200 VAC fuse and cable dimensions for international without USA / Canada
①
: Stranded with ferrule without plastic sleeve.
VFC x610
Model
Fuse
(gG)
Power cables installation mode
PE Cable Torque / Screw
B1 B2 E
[A]
[mm
2
] [mm
2
]
[N·m / lbf·in] (Mx)
0K40 6.0 2.5 2.5 2.5
10.0
0.8* / 7.0 (M3)
2.5*2
0K75 10.0 2.5 2.5 2.5
10.0
0.8* / 7.0 (M3)
2.5*2
1K50 10.0 2.5 2.5 2.5
10.0
0.8* / 7.0 (M3)
2.5*2
