VFC x610
Model
Fuse
(gG)
Power cables installation mode
PE Cable Torque / Screw
B1 B2 E
[A]
[mm
2
] [mm
2
]
[N·m / lbf·in] (Mx)
2K20 16.0 2.5 2.5 2.5
10.0
0.8* / 7.0 (M3)
2.5*2
3K00 20.0 4.0 4.0 2.5
10.0
0.8* / 7.0 (M3)
4.0*2
4K00 20.0 4.0 4.0 2.5
10.0
0.8* / 7.0 (M3)
4.0*2
5K50 32.0 6.0 6.0 4.0
10.0
1.2* / 10.5 (M4)
6.0*2
7K50 40.0 6.0 10.0 6.0
10.0
1.2* / 10.5 (M4)
6.0*2
11K0 50.0 10.0 10.0 10.0 10.0 1.2 / 15.0 (M4)
15K0 50.0 10.0 10.0 10.0 10.0 1.2 / 15.0 (M4)
18K5 80.0 25.0 25.0 16.0 16.0 3.73 / 33.0 (M5)
22K0 100.0 25.0 35.0 25.0 25.0 3.73 / 33.0 (M5)
30K0 125.0 35.0 50.0 35.0 25.0 3.80 / 33.6 (M6)
37K0 125.0 35.0 50.0 35.0 35.0 3.80 / 33.6 (M6)
45K0 160.0 50.0 70.0 50.0 35.0 31.1 / 275.0 (5/16 in)
55K0 200.0 70.0 95.0 70.0 50.0 31.1 / 275.0 (5/16 in)
75K0 250.0 120.0 150.0 95.0 95.0 31.1 / 275.0 (5/16 in)
90K0 250.0 120.0 150.0 95.0 95.0 31.1 / 275.0 (5/16 in)
110K 315.0
120.0 150.0 120.0
95.0
15.0 / 132.7 (M10)
①
95.0*2 95.0*2 95.0*2
8.0 / 70.8 (M8)
②
132K 315.0
185.0 240.0 185.0
120.0
15.0 / 132.7 (M10)
①
95.0*2 95.0*2 95.0*2
8.0 / 70.8 (M8)
②
160K 400.0 120*2 120*2 120*2 150.0
15.0 / 132.7 (M10)
②
185K 400.0 120*2 150*2 120*2 150.0
15.0 / 132.7 (M10)
②
200K 500.0 120*2 185*2 70*2 185.0
15.0 / 132.7 (M10)
②
220K 500.0 150*2 240*2 95*2 240.0
15.0 / 132.7 (M10)
②
Tab. 2-2: 3P 380 VAC fuse and cable dimensions for international without USA / Canada
①
and
②
: According to the actual situation, single cable or double ca-
ble can be selected as the power cable of model 110K and above.
①
is the torque and screw of single cable and
②
is the torque and
screw of double cable.
16/91
Electric Installation
Rexroth Frequency Converter VFC
3610 / VFC 5610
Bosch Rexroth AG R912005518_Edition 16
