C2: V/f control parameters
Code Name Setting range Default Min. Attri.
C2.00 V/f curve mode
0: Linear
1: Square
2: User-defined
3: V/f separation
0 – Stop
C2.01 V/f frequency 1 0.00...[C2.03] Hz 0.00 0.01 Stop
C2.02
V/f voltage 1
①
0.0...120.0 % 0.0 0.1 Stop
C2.03 V/f frequency 2 [C2.01]...[C2.05] Hz 0.00 0.01 Stop
C2.04
V/f voltage 2
①
0.0...120.0 % 0.0 0.1 Stop
C2.05 V/f frequency 3 [C2.03]...[E0.08] Hz 50.00 0.01 Stop
C2.06
V/f voltage 3
①
0.0...120.0 % 100.0 0.1 Stop
C2.07 Slip compensation factor 0…200 % 0 1 Run
C2.08
V/f separation output voltage
source selection
0: Panel potentiometer
1: Panel button setting
2: AI1 analog input
10: X5 pulse input
20: Communication (Modbus
0x7F0B/Fieldbus extension
card H0.50)
22: Digital setting
23: Voltage PID control
22 – Stop
C2.09
V/f separation output voltage
digital setting
0.00...100.00 % 0.00 0.01 Run
C2.10
V/f separation output voltage
acceleration time
0.0...6,000.0 s 0.0 0.1 Run
C2.11
V/f separation output voltage
deceleration time
0.0...6,000.0 s 0.0 0.1 Run
C2.12
V/f separation stop mode se-
lection
0: Voltage and frequency de-
celerates independently
1: Voltage decelerates to zero,
then frequency decelerates to
zero
0 – Run
C2.13 V/f separation boost factor 0.00...100.00 0.00 0.01 Run
C2.20 0 Hz output mode
0: No output
1: Standard
1 1 Stop
