E1: Input terminal parameters
Code Name Setting range Default Min. Attri.
E1.00 X1 input
0...51
35 – Stop
E1.01 X2 input 36 – Stop
E1.02 X3 input 0 – Stop
E1.03 X4 input 0 – Stop
E1.04 X5 input 0 – Stop
E1.15 2-wire/3-wire control mode 0...4 0 – Stop
E1.16 Digital input Up / Down change rate 0.10...100.00 Hz/s 1.00 0.01 Run
E1.17
Digital input Up / Down initial
frequency
0.00...[E0.09] Hz 0.00 0.01 Run
E1.25 Pulse input maximum frequency 0.0...50.0 kHz 50.0 0.1 Run
E1.26 Pulse input filter time 0.000...2.000 s 0.100 0.001 Run
E1.35 AI1 input mode 0: 0...20 mA
1: 4...20 mA
2: 0...10 V
3: 0...5 V
4: 2…10 V
2 – Run
E1.40 AI2 input mode 1 – Run
E1.38 AI1 gain 0.00...10.00 1.00 0.01 Run
E1.43 AI2 gain 0.00...10.00 1.00 0.01 Run
E1.60 Motor temperature sensor channel
0: Inactive
1: AI1 analog input
2: AI2 analog input
3: EAI1 analog input
4: EAI2 analog input
5: TSI input (only for IO
plus card)
0 – Stop
E1.61 Broken wire protection
0: Inactive
1: Warning
2: Error
0 – Stop
E1.68 Analog input curve setting 0...7 0 – Run
E1.69 Analog input filter time 0.000...2.000 s 0.100 0.001 Run
E1.70 Input curve 1 minimum 0.0 %...[E1.72] 0.0 0.1 Run
E1.71 Input curve 1 minimum frequency 0.00...[E0.09] Hz 0.00 0.01 Run
E1.72 Input curve 1 maximum [E1.70]...100.0 % 100.0 0.1 Run
E1.73 Input curve 1 maximum frequency 0.00...[E0.09] Hz 50.00 0.01 Run
