3.4.4 Group E: Function Control Parameters
E0: Set point and control parameters
Code Name Setting range Default Min. Attri.
E0.00 First frequency setting source 0...21 0 – Stop
E0.01 First run command source 0...2 0 – Stop
E0.02 Second frequency setting source 0...21 2 – Stop
E0.03 Second run command source 0...2 1 – Stop
E0.04
Frequency setting source
combination
0...6 0 – Stop
E0.06
Digital setting frequency
saving mode
0...4 0 – Stop
E0.07 Digital setting frequency 0.00...[E0.09] Hz 50.00 0.01 Run
E0.08 Maximum output frequency 50.00...400.00 Hz 50.00 0.01 Stop
E0.09 Output frequency high limit [E0.10]...[E0.08] Hz 50.00 0.01 Run
E0.10 Output frequency low limit 0.00...[E0.09] Hz 0.00 0.01 Run
E0.11 Reverse running frequency 0.00...[E0.09] Hz 0.00 0.01 Stop
E0.15 Low speed running setting
0: Run with 0.00 Hz
1: Run with low limit
frequency
0 – Stop
E0.16 Low speed frequency hysteresis 0.00...[E0.10] Hz 0.00 0.01 Stop
E0.17 Direction control
0: Forward / Reverse
1: Forward only
2: Reverse only
3: Swap default direction
0 – Stop
E0.18 Direction change dead time 0.0...60.0 s 1.0 0.1 Stop
E0.25
Acceleration / deceleration
curve mode
0: Linear mode
1: S-curve
0 – Stop
E0.26 Acceleration time 0.1...6,000.0 s DOM 0.1 Run
E0.27 Deceleration time 0.1...6,000.0 s DOM 0.1 Run
E0.28 S-curve starting phase factor 0.0...40.0 % 20.0 0.1 Stop
E0.29 S-curve stopping phase factor 0.0...40.0 % 20.0 0.1 Stop
E0.35 Start mode
0: Start directly
1: DC-braking before start
2: Start with speed tracing
3: Automatic start / stop ac-
cording to setting frequency
0 – Stop
