Code Name Setting range Default Min. Attri.
E0.36 Start frequency 0.00...50.00 Hz 0.05 0.01 Stop
E0.37 Start frequency holding time 0.0...20.0 s 0.0 0.1 Stop
E0.38 Start DC-braking time
0.0...20.0 s
(0.0: Inactive)
0.0 0.1 Stop
E0.39
Start DC-braking current
①
0.0...150.0 % 0.0 0.1 Stop
E0.41
Automatic start / stop frequency
threshold
0.01…[E0.09] Hz 16.00 0.01 Stop
E0.42
Speed tracing voltage recovery
ratio
0...20 10 1 Stop
E0.43 Speed tracing deceleration time 0.5...20.0 s 2.0 0.1 Stop
E0.45 Power loss restart mode
0: Inactive
1: Active for panel control
2:
Active for digital input control
0 - Stop
E0.46 Power loss restart delay 0.0...10.0 s 1.0 0.1 Stop
E0.47 Run command priority
0: High priority
1: Low priority
0 - Stop
E0.50 Stop mode
0: Decelerating stop
1: Freewheeling stop 1
2: Freewheeling stop 2
0 - Stop
E0.51 Stop DC-braking waiting time 0.00...100.00 s 0.00 0.01 Stop
E0.52
Stop DC-braking initial
frequency
0.00...50.00 Hz 0.00 0.01 Stop
E0.53 Stop DC-braking time
0.0...20.0 s
(0.0: Inactive)
0.0 0.1 Stop
E0.54
Stop DC-braking current
①
0.0...150.0 % 0.0 0.1 Stop
E0.55 Overexcitation braking factor 1.00...2.00 1.10 0.01 Run
E0.56 Emergency stop action
0: Freewheeling stop
1: Decelerating stop
0 – Stop
E0.57
Emergency stop deceleration
time
0.1…6,000.0 5.0 0.1 Run
E0.60 Jog frequency 0.00...[E0.08] Hz 5.00 0.01 Run
E0.61 Jog acceleration time 0.1...6,000.0 s 5.0 0.1 Run
E0.62 Jog deceleration time 0.1...6,000.0 s 5.0 0.1 Run
E0.70 Skip frequency 1 0.00...[E0.09] Hz 0.00 0.01 Stop
E0.71 Skip frequency 2 0.00...[E0.09] Hz 0.00 0.01 Stop
52/91
Start-up
Rexroth Frequency Converter VFC
3610 / VFC 5610
Bosch Rexroth AG R912005518_Edition 16
