H8: I/O card parameters
Code Name Setting range Default Min. Attri.
H8.00 EX1 input
0...51
0 – Stop
H8.01 EX2 input 0 – Stop
H8.02 EX3 input 0 – Stop
H8.03 EX4 input 0 – Stop
H8.04 EX5 input 0 – Stop
H8.05 EAI1 input mode
0: 0...20 mA
1: 4...20 mA
2: 0…10 V
3: 0…5 V
4: 2...10 V
5: -10...10 V
0 – Stop
H8.06 EAI1 input polarity setting 0...2 1 – Stop
H8.07 EAI1 dead zone filter value 0.0...30.0 % 0.0 0.1 Run
H8.09 EAI1 filter time 0.000...2.000 0.100 0.001 Run
H8.10 EAI1 gain 0.00...10.00 1.00 0.01 Run
H8.15 EAI1 curve minimum -120.0 %...[H8.17] 0.0 0.1 Run
H8.16 EAI1 curve minimum value -[E0.09]...[E0.09] Hz 0.0 0.1 Run
H8.17 EAI1 curve maximum [H8.15]...120.0 % 100.0 0.1 Run
H8.18 EAI1 curve maximum value -[E0.09]...[E0.09] Hz 50.0 0.1 Run
H8.20 EDO1 output selection
0...25
1 – Stop
H8.21 Extended relay output selection 1 – Stop
H8.22 EDO2 output selection 1 – Stop
H8.23
Extended digital output value from
extension card fieldbus communica-
tion
Bit0: EDO1 (IO / IO plus card)
Bit1: EDO2 (IO plus card)
Bit8: Erelay (IO card)
0 – Stop
H8.25 EAO output mode
0: 0…10 V
1: 0...20 mA
2: -10...10 V (only for IO plus
card)
0 – Run
