Code Name Setting range Default Min. Attri.
H1.30
Input PZD 1
②
0: Not used
1: Status word
2: Extended status word
3: Empty PZD
100: d0.00 (Output frequency)
101...199: d0.01...d0.99 (Moni-
toring values)
1 1 Stop
H1.31 Input PZD 2 100 1 Stop
H1.32 Input PZD 3 0 1 Stop
H1.33 Input PZD 4 0 1 Stop
H1.34 Input PZD 5 0 1 Stop
H1.35 Input PZD 6 0 1 Stop
H1.36 Input PZD 7 0 1 Stop
H1.37 Input PZD 8 0 1 Stop
H1.38 Input PZD 9 0 1 Stop
H1.39 Input PZD 10 0 1 Stop
①
: Output PZD 1...Output PZD 10 are the process data containers for
data transferring from PROFIBUS master to slave.
②
: Input PZD 1...Input PZD 10 are the process data containers for da-
ta transferring from PROFIBUS slave to master.
