3.4.8 Group d0: Monitoring Parameters
Code Name Minimum unit
d0.00 Output frequency 0.01 Hz
d0.01 Actual speed 1 rpm
d0.02 Setting frequency 0.01 Hz
d0.03 Setting speed 1 rpm
d0.04 User-defined setting speed 0.1
d0.05 User-defined output speed 0.1
d0.06 Encoder frequency 0.01
d0.07 Encoder speed 1
d0.09 V/f separation setting voltage 0.01 V
d0.10 Output voltage 1 V
d0.11 Output current 0.1 A
d0.12 Output power 0.1 kW
d0.13 DC-bus voltage 1 V
d0.14 Energy saving counter kWh 0.1 kWh
d0.15 Energy saving counter MWh 1 MWh
d0.16 Output torque 0.1 %
d0.17 Setting torque 0.1 %
d0.18 FWD speed limitation setting 0.01 rpm
d0.19 REV speed limitation setting 0.01 rpm
d0.20 Power module temperature 1 °C
d0.21 Actual carrier frequency 1 kHz
d0.23 Power stage running time 1 h
d0.30 AI1 input 0.01 V / 0.01 mA
d0.31 AI2 input 0.01 V / 0.01 mA
d0.33 I/O card EAI1 input 0.01 V / 0.01 mA
d0.34 I/O card EAI2 input 0.01 V / 0.01 mA
d0.35 AO1 output 0.01 V / 0.01 mA
d0.37 I/O card EAO output 0.01 V / 0.01 mA
d0.38 IO plus card TSI input signal value 0.001 V
d0.40 Digital input 1 –
d0.43 I/O card digital input –
d0.45 DO1 output –
d0.47 I/O card EDO1 output –
d0.48 I/O card EDO2 output –
d0.50 Pulse input frequency 0.01 kHz
d0.55 Pulse output frequency 0.1 kHz
