: Detailed descriptions on (-) and (+) in the Operating Instructions must be
read through and followed before any operation on these two terminals.
Fig. 2-4: Grounding and PE terminals
1. Grounding terminal for mains cables
2. Reserved for PE / shielding adapter (Order additionally)
3. Reserved for PE / shielding adapter (Order additionally)
4. Grounding terminal for motor cables
Rexroth Frequency Converter VFC
3610 / VFC 5610
21/91
Electric Installation
R912005518_Edition 16 Bosch Rexroth AG
