RGBlink CP 3072 User Manual

5. System Setup and Operation
How to Set up the PIP
CP 3072 User Manual 54
How to Set up the PIP
Push the [PIP] button in PIP Operation Area, and enter to the PIP function
menus. Turn the knob and choose <PIP> option, push the knob to confirm. Turn
the knob, choose ON to enable the PIP function.
LAYOUT: There are 7 kinds of PIP layouts, PIP L+T, PIP R+T, PIP L+B, PIP
R+B, PIP CENT, PBP L+R and PBP T+B. Take 3 results for example, shown as
follows:
PIP L+T PBP L+R PBP T+B
SELECT: Choose the channel for operation, user can choose the channel of A
BUS or B BUS.
>PIP ON
LAYOUT PIP L+T
SELECT A BUS
