5. System Setup and Operation
How to Realize the DSK Setting
CP 3072 User Manual 57
How to Realize the DSK Setting
1. First, set PIP mode, or user can not set DSK.
2. Push the [DSK] button in DSK Operation Area, the OLED panel show
as follows:
SELECT: User can choose the signal of A BUS channel or B BUS channel.
MODE: There are 2 kinds of preset modes, DSK and KEY.
COLOR: The colors include white, yellow, cyan, green, red, blue and black.
BACKGROUND: User can choose black or blue.
Y, Cb, Cr OFFSET. User can optimize the effect if DSK or KEY is poor by
color offset setting. Suggest priority setting of Y offset. If image quality
distorts by improper operation, it can be recover by reset
3. Turn the KEY LEVEL knob to set the Alpha, the adjustment range is 0 to
100.
SELECT A BUS
>MODE DSK
COLOR WHITE
BACKDROUND: BLACK/BLUE
>Y OFFSET 0
Cb OFFSET 0
Cr OFFSET 0
RESET
To Next Page
