RGBlink CP 3072 User Manual

CP 3072 User Manual 63
A. Specification
CVBS BNC Input
Number of Inputs
4
Supported Standards
PAL/NTSC/SECAM
Signal Level
1Vpp±3db (0.7V Video+0.3v Sync ) 75 ohm
Multiplex
480i,576i
VGA DB15 Input
Number of Inputs
4
Connector
Standard DB15 Socket
Supported Standard
VGA-UXGA
Signal Level
R、G、B、Hsync、Vsync:0 to1Vpp±3dB (0.7V Video+0.3v
Sync ) 75 ohm
black level: 300mV Sync-tip: 0V
Supported Resolution
VGA-UXGA
USB Input
Number of Inputs
4
Connector
Standard USB port
Supported Standard
Support general Image and video formats (CP 3072 V1.1
can only support video formats)
HDMI Input (Only for CP 3072)
Number of Inputs
4
Connector
HDMI standard type A interface
Supported Resolution
SMPTE: 625/25 PAL, 525/29.97 NTSC, 625/50p PAL,
525/59.94p NTSC 720p50,720p59.94/60, 1080i50,
1080i59.94/60
VESA: 1024×768@60Hz, 1280×768@60Hz,
1280×1024@60Hz, 1920×1080@60Hz,
1920×1080@50Hz
Embedded Audio
Channels
Choose 1 in 2
Format Standard
HDMI 1.3
3G-SDI Input (Only for CP 3072S)
Number of Inputs
4
Connector
BNC
Data Rate
2.97Gb/s, 2.97/1.001Gb/s, 1.485Gb/s, 1.485/1.001Gb/s
and 270Mb/s
Supported Standard
SMPTE 425M (Level A and Level B), SMPTE424M, SMPTE
292M, SMPTE 259M-C and DVB-ASI
Balance
Belden 1694A cable:
150m at 2.97Gb/s
