RGBlink CP 3072 User Manual

CP 3072 User Manual 64
250m at 1.485Gb/s
480m at 270Mb/s
CVBS Program Output
Number of Outputs
1
Supported Standards
PAL/NTSC/SECAM
Signal Level
1Vpp±3db (0.7V Video+0.3v Sync ) 75 ohm
HDMI Program Output
Number of Outputs
1
Connector
HDMI standard type A interface
Supported Resolution
VESA: 1024×768@60Hz, 1280×768@60Hz,
1280×1024@60Hz, 1920×1080@60Hz,
1920×1080@50Hz
Format Standard
HDMI 1.3, DVI 1.0
VGA Program Output
Number of Outputs
1
Connector
Standard DB15 Socket
Supported Resolution
VESA: 1024×768@60Hz, 1280×768@60Hz,
1280×1024@60Hz, 1920×1080@60Hz,
1920×1080@50Hz
Signal Level
R、G、B、Hsync、Vsync:0 to1Vpp±3dB (0.7V Video+0.3v
Sync ) 75 ohm
black level: 300mV Sync-tip: 0V
HDMI Preview Output
Number of Outputs
1
Connector
HDMI standard type A interface
Supported Resolution
VESA: 1024×768@60Hz, 1280×768@60Hz,
1280×1024@60Hz, 1920×1080@60Hz,
1920×1080@50Hz
Format Standard
HDMI 1.3, DVI 1.0
VGA Preview Output
Number of Outputs
1
Connector
Standard DB15 Socket
Supported Resolution
VESA: 1024×768@60Hz, 1280×768@60Hz,
1280×1024@60Hz, 1920×1080@60Hz,
1920×1080@50Hz
Signal Level
R、G、B、Hsync、Vsync:0 to1Vpp±3dB (0.7V Video+0.3v
Sync ) 75 ohm
black level: 300mV Sync-tip: 0V
HDMI PVW Output
Number of Outputs
1
Connector
HDMI standard type A interface
Supported Resolution
1024×768@60Hz
