Press “ ”twice, the screen will displays two rows of arrows which are
defaults to all arrows are downwards “↓”.
Upper arrows represent input signal: the former 4 numbers 0, 1, 2, 3
corresponding to X zero, Y zero, Z zero and tool setting gauge. 4,5,6 corresponding to
driver alarm, hard limit and emergency stop input signal.
Manual trigger the corresponding signal switch by pressing “ ”and the
corresponding arrow flip so the signal is normal.
Bottom row represent output signal: the former 4 number 0,1,2,3 corresponding
to spindle on/off、multistep rotational speed one、multistep rotational speed two、
multistep rotational speed three output signal.4，5 corresponding to alarm lamp、
running lamp output signal.
Press “ ” button can change the arrow direction, so it can control the
output of corresponding port. For example, press “ ”to flip the arrow upwards
under 0, it is equivalent to start the spindle. Press“ ” again, the arrow flip
downwards that is equivalent to stop the spindle.
5.3.4 Manual testing input and output
Including machine coordinate system and work coordinate system.
Machine coordinate system is fixed, the origin of coordinates is always a fixed
position relative to the machine; Its coordinates is called mechanical values, the origin
of coordinates is the origin of the machine or reference point. so that at any time, one
point of space can be confirmed by machine coordinate system. Because of reference
point is the calculation basis of machine coordinates movement，powered on or
