17
D19
Power LED
Interface board 5V
indicator indicate
the interface
andinternal power
supply status
moderators
Lights after
power
D11
Status indicator
X origin status
indicator
Light after
power.
Input low
level signal,
the lights
will be put
out.
Release the
signal,the
lights will be
bright again
D12
Status indicator
Y origin status
indicator
D13
Status indicator
Z origin status
indicator
D14
Status indicator
Tool-setting Status
indicator
D15
Status indicator
Driver alarm
status indicator
D16
Status indicator
Hard Limit status
indicator
D17
Status indicator
E-stop status
indicator
D18
Status indicator
Definable signal
status indicator
D1
Status indicator
output terminal
Y1 status indicator
Output low
level signal
when the
system
works
D2
Status indicator
output terminal
Y2 status indicator
D3
Status indicator
output terminal
Y3 status indicator
D4
Status indicator
output terminal
Y4 status indicator
D5
Status indicator
output terminal
Y5status indicator
D6
Status indicator
output terminal
Y6status indicator
D7
Status indicator
output terminal
Y7 status indicator
D8
Status indicator
output terminal
Y8 status indicator
 3.3 Hardware Wiring
Installation Requirements：Power（24V，3A），it is better to add a filter to prevent
