In the process of processing, the screen scrolling display real-time processing
speed,operation time、current line number. We can switch these options by
pressing “ ”.
5.5 During processing operations
5.5.1 Speed ratio & spindle grade Adjusting
1) Adjust speed ratio
In process of processing, press “ ”、“ ” can directly change speed
ratio, current speed= set speed * ratio, each push on “ ” or “ ”, the speed
ratio will go up or dwon drop 0.1. Speed ratio:max 1.0, min 0.1, the displayed speed
will corresponding to the changing of speed ratio, but time will not change.
2) Adjust spindle grade
If user has set multistep speed, the DSP handle can change the multistep speed
in process of processing. Press “ ” and “ ” to change spindle grade.
Each push of “ ” and “ ” will go up or dwon drop 1 grade till to S8 or
S1.
5.5.2 Pause & adjust position
Press “ ” pause processing. The right upwards of screen will change
from“MAUN” to “PAUZ”and machine paused processing except the rotating of
spindle. Shown below:
1X 7.000 PAUS
1Y 8.000 S2
1Z -2.000 H SP
User will start
