At this moment, the user is allowed to adjust the position of X, Y and Z axis.
The system default motion mode is STEP. So that user can fine adjust each axis
distance. Machine moves one low or high speed grid distance every step. Meanwhile,
user can change the speed mode to high mode just press “ ”.
When the adjustment is finished, press “ ” again, screen shows below:
The system asks the user whether save the modified position. Press “ ”/
“ ” the system will start processing in modified position, press “ ”,
system will back to the position before modifying.
5.5.3 Breakpoint processing & power down protection
1) Breakpoint processing
If user presses “ ” during process of processing, the screen shows below:
If we want to save breakpoint, press “ ”,the screen displays break
list(totally 8), press “ ”、“ ”to choose the save position and then
press “ ” to save, system auto go to standard interface. If we want to
Save break？
保存断点
Discard break
Save break
U 盘 文 件 件
WENJIAN
1X 7.200 PAUS
1Y 41.300 S2
1Z -0.200 H SP
Restore Position？
