SP6xxx: Peripherals
D017/D018/D019/D020 5-148 SM
- Value: Moves the staple position to the front side.
1 Finisher 1 (B408/B793) [-3.5 to 3.5 / 0 / 1/step]]
2 Finisher 2 (D372) [-2.0 to 2.0 / 0 / 1/step]]
6134 Saddle Stitch Position Adjustment
Use this SP to adjust the stapling position of the booklet stapler when paper
is stapled and folded in the Booklet Finisher B793.
1 A3 SEF
2 B4 SEF
3 A4 SEF
4 B5 SEF
5 DLT-T (SEF)
6 LG-T (SEF)
7 LT-T (SEF)
8 12" x 18"
9 Other
[-3.0 to 3.0 / 0 / 0.2 mm/step]
+ Value: Shifts staple position toward the crease.
- Value: Shifts staple position away from the
crease.
6135 Folder Position Adjustment
This SP corrects the folding position when paper is stapled and folded in the
Booklet Finisher B793.
1 A3 SEF
2 B4 SEF
3 A4 SEF
4 B5 SEF
5 DLT-T (SEF)
[-3.0 to 3.0 / 0 / 0.2 mm/step]
+ Value: Shifts staple position toward the crease.
- Value: Shifts staple position away from the crease.
