SP6xxx: Peripherals
SM 5-155 D017/D018/D019/D020
Service
Tables
10 Positioning Roller Solenoid Positioning Roller Solenoid
11 Stack Feed-out Motor -
12 Shift Motor -
13 Exit Guide Plate Motor -
FIN (ELB) Input Check 500-Sheet Finisher D372
6145
Displays the signals received from sensors and switches of the finisher.
Note:
The names in parentheses below are the names used in the service
manuals.
"0" means LOW, "1" means HIGH.
Component 0 1
1 Entrance Sensor Paper No Paper
2
Hitroll HP Sensor
(Positioning Roller HP Sensor)
Not HP At HP
3
Front Jogger HP Sensor
(Front Fence HP Sensor)
Not HP At HP
4
Rear Jogger HP Sensor
(Rear Fence HP Sensor)
Not HP At HP
5 Staple Tray Paper Sensor Paper No Paper
6
Staple Moving HP Sensor
(Stapler HP Sensor)
Not HP At HP
7 Stack Feed-Out Belt HP Sensor Not HP At HP
8 Shift Tray Paper Sensor Not HP At HP
9 Upper Cover Sensor Not HP At HP
10 Stapler Rotation Sensor HP Not HP
