Specifications
D017/D018/D019/D020 7-2 SM
Warm-up Time
Basic: Less than 12 sec.
Operation Key: Less than 10 sec.
LCD on: Less than 3 sec.
Standby: Less than 6 sec.
Scan Start: Less than 6 sec.
Continuous Copies 001 to 999 Sheets
Zoom
Platen Mode: 25% to 400%
ARDF Mode: 25% to 200%
Paper Supply
Tray 1, 2: 500 Sheets
Bypass: 100 Sheets
Output Capacity
A4, smaller: 500 Sheets face-down
B4, larger: 250 Sheets face-down
Power Source
NA: 120V 60 Hz
EU: 220 to 240V 50/60 Hz (Asia, China)
Taiwan: 110V 60 Hz
Full System (Operating) Less than 1.4 KW
Off Mode Less than 1.65 W
Power Consumption
Sleep Mode
Less than 6 W (NA
Less than 6.5 W (EU)
Dimensions (w x d x h)
Standard No PTU
570 x 653 x 709 mm
(22.4 x 25.7 x 30 in.)
With PTU
570 x 653 x 980 mm
(22.4 x 25.7 x 38.6 in.)
Duplexer With Duplexer (No PTU)
630 x 653 x 709 mm
(24.8 x 25.7 x 30 in.)
With Duplexer (With PTU)
630 x 653 x 980 mm
(24.8 x 25.7 x 38.6 in.)
