ELECTRICAL COMPONENT LAYOUT
SM 3 D367
1-Bin Tray
BN3030
D367
1.3 ELECTRICAL COMPONENT LAYOUT
1. Paper Sensor
2. 1-bin Sorter Exit Tray LED
(located in the copier)
1.4 ELECTRICAL COMPONENT DESCRIPTION
Symbol Name Function Index No.
Sensors
S1 Paper Detects when there is paper on the tray. 1
LEDs
LED1
1 Bin Exit Tray Indicates when there is paper in the tray. This
sensor is located in the copier.
2
B413V502.WMF
1
2
