Electrical Components
D372 54 SM
Switches
SW1 Stapler Door Switch
Detects when the stapler top cover is open or
closed.
SW2 Top Cover Switch Detects when the top cover is opened or closed.
SW3 Tray Upper Limit Switch
If the tray becomes full, the top of the stack will
push up a plate that activates this switch and
switches off the finisher. This is a backup feature
that will shut down operation if the tray full
sensor or paper height sensor fails with the
output tray full.
Other
Stapler Stapler Unit Staples sheets stacked on the stapling tray.
