Bit Switches
SM 101 D361
Fax Option
Type 3350
D361
Communication Switch 1C (SP No. 1-104-029)
No Function Comments
2-7 Not used Do not change the settings.
Communication Switch 1D - Not used (do not change the settings)
Communication Switch 1E - Not used (do not change the settings)
Communication Switch 1F - Not used (do not change the settings)
4.3.5 G3 SWITCHES
G3 Switch 00 (SP No. 1-105-001)
No Function Comments
Monitor speaker during
communication (tx and rx)
Bit 1 Bit 0 Setting
0 0 Disabled
0 1 Up to Phase B
1 0 All the time
1 1 Not used
0
1
(0, 0): The monitor speaker is disabled all
through the communication.
(0, 1): The monitor speaker is on up to
phase B in the T.30 protocol.
(1, 0): Used for testing. The monitor
speaker is on all through the
communication. Make sure that you reset
these bits after testing.
2
Monitor speaker during memory
transmission
0: Disabled 1: Enabled
1: The monitor speaker is enabled during
memory transmission.
3-7 Not used Do not change the settings.
