Copy Adjustments: Printing/Scanning
SM 3-63 D017/D018/D019/D020
Replacement
and
Adjustment
SP mode Specification
Leading edge SP2-101-1 3 ± 2 mm
Left edge SP2-101-5 2 ± 1.5 mm
Trailing edge (duplex
copy, 2nd side)
SP2-101-7 2 ± 2 mm
Left edge (duplex copy,
2nd side)
SP2-101-8 2 ± 1.5 mm
Right edge (duplex
copy, 2nd side)
SP2-101-9 2 +2.5/-1.5 mm
A: Trailing Edge Blank Margin
B: Right Edge Blank Margin
C: Leading Edge Blank Margin
D: Left Edge Blank Margin
Main Scan Magnification
1. Print the single-dot grid pattern (SP2-902, no.5).
