Copy Adjustments: Printing/Scanning
SM 3-67 D017/D018/D019/D020
Replacement
and
Adjustment
stations.
2. Check the registration, and adjust using the following SP modes if necessary.
SP mode
Side-to-side Registration SP6-006-1
Leading Edge Registration (Simplex) SP6-006-2
Trailing Edge Blank Margin SP6-006-3
Sub Scan Magnification
 Make a temporary test chart as shown above using A3/DLT paper.
1. Place the temporary test chart on the ADF and make a copy from one of the feed
stations.
2. Check the magnification, and adjust using the following SP modes if necessary. The
specification is ±1%.
SP mode
Sub scan magnification SP6-006-5
3.10.4 TOUCH SCREEN CALIBRATION
After clearing the memory, or if the touch panel detection function is not working correctly,
follow this procedure to calibrate the touch screen.
 Do not attempt to use items [2] to [9] on the Self-Diagnostic Menu. These items
are for design use only.
1. Press J, input 1993 at the ten-key pad, and then press D 5 times to open the
Self-Diagnostics menu.
To Next Page
