SP6xxx: Peripherals
D017/D018/D019/D020 5-156 SM
11 Staple Near End Sensor HP Not HP
12 Self Priming (Stapler) HP Not HP
13
Shift Tray Limit Sensor
(Tray Upper Limit SW)
Not Full Full
FIN (ELB) Output Check 500-Sheet Finisher D372
6146
Displays the signals received from sensors and switches of the booklet
finisher.
Note: In the table below, "Display" is what you see on the screen, and
"Component" is the name used in the service manuals.
Display Component
1 Carry Motor Transport Motor
2 Hitroll Motor Positioning Roller Arm Motor
3 Front Jogger Motor Front Fence Motor
4 Rear Jogger Motor Rear Fence Motor
5 Staple Moving Motor Stapler Movement Motor
6 Stack Feed-Out Motor Feed-Out Belt Motor
7 Tray Motor Tray Lift Motor
8 Staple Motor Stapler Motor
9 Stopper Solenoid Stack Depressor Solenoid
